Lister Type › Single Cylinder Diesel Engine
 |
|
6 HP Diesel Engine Specification
| Type |
Lister Type Diesel Engine |
| Model |
PS6 |
| Type |
Four Stroke, Compression Ignition, Vertical, Water Cooled, Handle Start, Indirect injection, Constant Speed, Fly wheel balanced Stationery Diesel Engine |
| Power HP/kw |
6/4.4 |
| Speed RPM |
650 |
| Bore MM |
114.3 |
| Stroke MM |
139.7 |
| Cubic Capacity CC |
1433 |
| Compression Ratio |
1:16 |
| Fuel Consumption (max) |
1166 g/hr (1.4 Lit/hr) |
| Lubricating oil consumption |
10 cc / hr max |
| Fuel |
HSDO / LDO |
| Lubricating oil |
YENTROL-32B / SAE-30/40 |
| Net Weight Kg |
300 |
| Gross Weight Kg |
390 |
| Packing Size |
105 X 70 X 114 CMS |
| Standard accessories: |
Starting Handle, Air Cleaner, Silencer, Spanner Set, Screw Driver, Oil Can, Flat Pulley (12 x 5 x 2 Inch), Instruction Manual & Tool Bag. |
| Application: |
Widely Use As a Prime Mover For Water Pump Sets, Power Generating Sets, Floor Mills, Hullers, Cement Concrete Mixture Machine, Turbines, Saw Mills, Mining and Construction Hoists. |
|
|
|
| |
 |
|
8 HP Diesel Engine Specification
| Type |
Lister Type Diesel Engine |
| Model |
PS8 |
| Type |
Four Stroke, Compression Ignition, Vertical, Water Cooled, Handle Start, Indirect injection, Constant Speed, Fly wheel balanced Stationery Diesel Engine |
| Power HP/kw |
8/5.9 |
| Speed RPM |
850 |
| Bore MM |
114.3 |
| Stroke MM |
139.7 |
| Cubic Capacity CC |
1433 |
| Compression Ratio |
1:18 |
| Fuel Consumption (max) |
1581 g/hr (1.9 Lit/hr) |
| Lubricating oil consumption |
10 cc / hr max |
| Fuel |
HSDO / LDO |
| Lubricating oil |
YENTROL-32B / SAE-30/40 |
| Net Weight Kg |
300 |
| Gross Weight Kg |
390 |
| Packing Size |
105 X 70 X 114 CMS |
| Standard accessories: |
Starting Handle, Air Cleaner, Silencer, Spanner Set, Screw Driver, Oil Can, Flat Pulley (12 x 5 x 2 Inch), Instruction Manual & Tool Bag. |
| Application: |
Widely Use As a Prime Mover For Water Pump Sets, Power Generating Sets, Floor Mills, Hullers, Cement Concrete Mixture Machine, Turbines, Saw Mills, Mining and Construction Hoists. |
|
|
|
| |
 |
|
10 HP Diesel Engine Specification
| Type |
Lister Type Diesel Engine |
| Model |
PS10 |
PS10 CBW |
| Type |
Four Stroke, Compression Ignition, Vertical, Water Cooled, Handle Start, Indirect injection, Constant Speed, Fly wheel balanced Stationery Diesel Engine |
| Power HP/kw |
10/7.35 |
10/7.35 |
| Speed RPM |
1000 |
1000 |
| Bore MM |
120 |
120 |
| Stroke MM |
139.7 |
139.7 |
| Cubic Capacity CC |
1580 |
1580 |
| Compression Ratio |
1:18 |
1:18 |
| Fuel Consumption (max) |
1970 g/hr (2.37 Lit/hr) |
1970 g/hr (2.37 Lit/hr) |
| Lubricating oil consumption |
10 cc / hr max |
10 cc / hr max |
| Fuel |
HSDO / LDO |
HSDO / LDO |
| Lubricating oil |
YENTROL-32B / SAE-30/40 |
YENTROL-32B / SAE-30/40 |
| Net Weight Kg |
320 |
320 |
| Gross Weight Kg |
410 |
410 |
| Packing Size |
105 X 70 X 114 CMS |
105 X 70 X 114 CMS |
| Standard accessories: |
Starting Handle, Air Cleaner, Silencer, Spanner Set, Screw Driver, Oil Can, Flat Pulley (12 x 5 x 2 Inch), Instruction Manual & Tool Bag. |
| Application: |
Widely Use As a Prime Mover For Water Pump Sets, Power Generating Sets, Floor Mills, Hullers, Cement Concrete Mixture Machine, Turbines, Saw Mills, Mining and Construction Hoists. |
|
|
|
| |
|
|
12 HP Diesel Engine Specification
| Type |
Lister Type Diesel Engine |
| Model |
PS12 |
| Type |
Four Stroke, Compression Ignition, Vertical, Water Cooled, Handle Start, Indirect injection, Constant Speed, Crankshaft Balanced, Stationery Diesel Engine |
| Power HP/kw |
12/8.8 |
| Speed RPM |
1000 |
| Bore MM |
127 |
| Stroke MM |
146.05 |
| Cubic Capacity CC |
1850 |
| Compression Ratio |
1:18 |
| Fuel Consumption (max) |
2365 g/hr (2.85 Lit/hr) |
| Lubricating oil consumption |
15 cc / hr max |
| Fuel |
HSDO / LDO |
| Lubricating oil |
YENTROL-32B / SAE-30/40 |
| Net Weight Kg |
365 |
| Gross Weight Kg |
455 |
| Packing Size |
105 X 70 X 114 CMS |
| Standard accessories: |
Starting Handle, Air Cleaner, Silencer, Spanner Set, Screw Driver, Oil Can, Flat Pulley (12 x 5 x 2 Inch), Instruction Manual & Tool Bag. |
| Application: |
Widely Use As a Prime Mover For Water Pump Sets, Power Generating Sets, Floor Mills, Hullers, Cement Concrete Mixture Machine, Turbines, Saw Mills, Mining and Construction Hoists. |
|
|
|
|
|
|
|
|
|
|
 |
|
